UPVC Column Pipes

Get a Price/Quote

MOQ : 100 Pieces

UPVC Column Pipes Specification

Connection Type
Male/Female Threaded Ends

Flexibility
Rigid

Tensile Strength
450 kg/cm2 (approx)

Sealing Type
Rubber O-Ring Sealing

Diameter
1 inch to 6 inches

Coating Type
Uncoated

Thread Type
Square Threads

Bend Radius
Not Flexible (Rigid Pipe)

Temperature Range
Up to 45C

Tolerance
0.5 mm

Yield Strength
~40 MPa

Product Type
UPVC Column Pipes

Material
PVC

Connection
Threaded Coupling

Shape
Round

Standard
Other

Surface Treatment
Smooth

Outer Diameter
33 mm - 165 mm (varies by model)

Section Shape
Circular

Length
3 Meters / 6 Meters

Thickness
2.0 mm - 6.0 mm (varies by model)

Color
White

Usage
Borewell Submersible Pump Installation

Rated Pressure
2.5 to 12.5 kg/cm2 (varies by class)

Material Grade
Virgin Food Grade UPVC

Application
Water Lifting, Irrigation, Agriculture, Domestic Wells

UV Resistance
High

Internal Finish
Mirror smooth for low friction loss

Life Span
Up to 50 years under normal conditions

Toxicity
Non-toxic and Safe for potable water

Hydrostatic Pressure Test
Up to rated class

Weight
Lightweight compared to metal pipes

Installation Method
Screw Joint

Corrosion Resistance
Excellent

Maintenance
Low maintenance

Chemical Resistance
Highly resistant to acids, alkalis, and salts

Crack Resistance
High impact resistance

Electrical Conductivity
Non-conductive

UPVC Column Pipes Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About UPVC Column Pipes

Owing to the optimum grade range of UPVC Column Pipes, we have gained huge commendation amongst customers. Thus, we are pondered as a major trader, supplier and service provider in the industry. The offered pipe is non-corrosive, hi-tech and hi-tensile as it's developed and designed under the strict surveillance of expert professionals using quality certified basic material and progressive technology. These pipes are the best alternative for These column pipes and are recommended for installations up to 1100 ft. Further, clients can avail of UPVC Column Pipes from us in different sizes and diameters at a reasonable price.

Exceptional Corrosion & Chemical Resistance

Made from premium virgin UPVC, these column pipes resist corrosion, scaling, and chemical degradation, even from acids, alkalis, and salts, ensuring durability in diverse borewell and water lifting environments. This property guarantees a safe supply of potable water and long-lasting service, particularly where metal pipes would succumb to rust or decay.

Easy Installation and Lightweight Design

Weighing significantly less than metal alternatives and featuring threaded screw joints with O-ring sealing, installation is easy and efficient. These pipes are safe to handle, require minimal manpower, and help speed up site work without heavy lifting machinery. The square threads and rubber O-rings ensure leak-proof, robust connections.

Engineered for Longevity and Safety

With a service life of up to 50 years and made from non-toxic, non-conductive UPVC, these pipes are safe for potable water applications. The sturdy structure, high impact-crack resistance, UV stability, and precise tolerance keep your water delivery system operational, even in harsh conditions, with minimal maintenance.

FAQ's of UPVC Column Pipes:

Q: How are UPVC column pipes installed, and what connection method is used?

A: Installation is straightforward thanks to the lightweight design and precision engineering. The pipes use a screw joint system with threaded male/female ends and rubber O-ring sealing, allowing for fast, leak-proof assembly without specialized tools or equipment.

Q: What are the primary benefits of using UPVC column pipes for borewell installations?

A: UPVC column pipes offer high corrosion and chemical resistance, excellent durability, a mirror-smooth internal surface for low friction loss, and non-toxic properties-making them ideal for potable water. Their light weight makes transportation and installation simple, saving time and labor costs.

Q: Where can UPVC column pipes be installed and in what applications?

A: These pipes are perfect for borewell submersible pumps, water lifting, agricultural irrigation, domestic wells, and drinking water systems. Their high UV and chemical resistance allow for dependable use in diverse climatic and water quality conditions across India and globally.

Q: When should I choose UPVC column pipes over metal or other pipe types?

A: Choose UPVC column pipes when you require a non-corrosive, lightweight, low-maintenance piping solution for water extraction and transport. They surpass metal pipes in areas prone to rust, chemical exposure, or difficult handling logistics, and are suitable for installations needing food-grade safety.

Q: What process ensures leak-proof sealing in UPVC column pipe systems?

A: These pipes use a threaded coupling system complemented by a high-quality rubber O-ring sealing. This process ensures robust, watertight joints capable of withstanding substantial pressure without risk of leakage or joint failure.

Q: How does the internal finish affect water flow in UPVC column pipes?

A: A mirror-smooth internal surface minimizes frictional loss, enhancing water flow efficiency and reducing pumping energy requirements. This results in improved performance of borewell systems and long-term energy savings.

Q: Are UPVC column pipes suitable for high-pressure and high-impact applications?

A: Yes, these pipes are engineered to handle high hydrostatic pressures (up to rated class) and possess high impact resistance, making them reliable for demanding water lifting and irrigation tasks.
